NEUTRIK - 3 WAY CABLE MOUNT XLR CONNECTOR. FEMALE. GOLD PLATED CONTACTS. 50 V

CARACTERISTIQUES :

• world's first unisex XLR
• 3 pole male and female cable connector in one housing
• easy selectable gender - converted by sliding housing back and forth
• substitute adapters, ideal as an emergency kit
• with all benefits of the XLR XX series

SPECIFICATIONS :

• connection type: XLR
• gender: female
• données éléctriques:
  • capacitance between contacts: = 4 pF
  • résistance de contact initiale: = 3 mohm
  • dielectric strength: 1.5 kVdc
  • insulation resistance: > 2 Gohm (initial)
  • rated current per contact: 16 A
  • rated voltage: < 50 V
• mécaniques:
  • cable O.D.: 3.5 - 8.0 mm
  • insertion force: = 20 N
  • withdrawal force: = 20 N
  • durée de vie: > 1000 cycles de connexion
  • wire size: max. 2.5 mm²
  • wire size: max. 14 AWG
  • câblage: solder contacts
  • locking device: latch lock
